Med Door
1 / 5
Classic Aesthetic Design: Crafted from premium galvanized steel with an extensive accessory range, featuring enhanced security and resilience. Suitable for any security-sensitive premises, with cost-effectiveness as its prime advantage.
Compliant with JG/T 125-2017 Grade 1-3. Load capacity ≥40kg with over 30,000 operation cycles.
Anti-picking duration ≥10 minutes. Features 14mm extended steel bolts with anti-prying design.
High yield strength (≥340MPa) and zinc coating (≥70g/m²) for superior impact resistance.
| Parameter | Description |
|---|---|
| Material Properties | Galvanized steel plates (Cold-Rolled) |
| Frame Thickness | Not less than 0.8mm (Customizable up to 1.4mm) |
| Door Leaf Thickness | Standard 70mm |
| Surface Finish | Powder coated / Transfer printing |
| Standard Size | 2050*960mm / 1970*860mm (Customizable) |
| Filler | Honeycomb paper core / Rock wool (Optional) |
Our facility is equipped with advanced heavy hydraulic moulding machines, CNC sheet metal combination tools, and electrostatic paint assembly lines. We operate under a unified management system to ensure real-time production tracking.
